Windchime Holder

Canyon Winds was given a sizable donation last year and fortunately the Percussion Section received a large percentage of it. Doug (our director) wants to have the band own their own percussion equipment rather than rely on each of the percussionists to bring in personal equipment. We had been using a windchime (really a Mark chime tree) belonging to one of the players so this was one item on our want list.
We chose a TreeWorks brand of windchime that cost us $150. Usually the mount for a windchime is an afterthought and it is mounted on an unused cymbal stand by removing the wing nut and sleeve, placing the windchime on the threaded part and then tightening the wing nut back on. This ends up having the windchime to pivot up and down when it's played making it difficult to play and dampen, plus visually it looks haphazard and sloppy.

Not only does this offend my sensibilities, but it goes against my philosophy: "Why buy a commercially made product for $25 when you can make one for $50?"
Actually I had all the parts left over from other projects. I used some 1" steel bar that I bent to shape, 8mm wing nut and bolt, hard felt, plastic tubing, and clamping system from an old cowbell mount. Some drilling and cutting produced a dedicated windchime mount that could be easily clamped to various diameter stands, solidly holding the windchimes in the proper position and most importantly getting rid of the need to replace missing wing nuts and cymbal felts that would be lost.

Mount

The Mount in use

Comments

La Caverna del oro

One of our first backpacking trips in Colorado was in the Sangre de Christo Mountains. One mountain in particular drew our attention. Marble Mountain was the location of a famous story of a Spanish cave of gold. There are many places on the web that tell this story better than I could, suffice it to say that we wanted to locate it and see the iconic 'Maltese Cross' located at it's entrance. In 1974 after I got out of the Army we invited some friends to join us on this trip. We parked our car at the trailhead in the Wet Mountain Valley and backpacked up Marble Mountain to 12,000 feet. In one of the culverts we found the entrance to the cave. Maltese Cross at the Caverna del oro It turned out to be a real thing. The large red cross was still visible after 400 yrs. According to legend the Spanish put it there in the 1600's. I did have the courage to crawl into it but only a few feet. After about 10 feet there is a vertical shaft that drops about 750 feet! The Cross is v...

Zenith tubes, Analema, and Crossed Trapezes

The Zenith Sun A common characteristic in Mesoamerica is the observance of the sun's zenith passage. This happens when the sun passes directly overhead at noon. It appears twice a year around late April and mid-August. Many ancient sites from Mexico east to the Yucatan seem to have systems built into their architecture to show this phenomenon. In the Mayan city of Kabah there is a cylindrical stone marker placed vertically in a plaza that seems to act as a gnomon that will produce a shadow every day except during the time of the sun's zenith position when the shadow disappears. In Monte Alban, Oaxaca and Xochicalco, Mexico the devices are more sophisticated. These have Zenith tubes in buildings that direct the rays of the sun down their passages to produce a circle of light onto the floor of a darkened chamber. Looking up through the zenith tube Sun light on the floor of Xochicalco zenith tube. The Mixtec A-O glyph The Mixtec A-O glyph was their symbol for 'year'. The...

The Amadinda

The Amadinda is an African xylophone originally made from slabs of wood or even large sticks, with or without gourds for resonators. There was no reason for this project other than to see if I could make a simple mallet instrument. The box was made from plywood (which also acted as the resonators) and the bars were made from maple. Since this was to be a true xylophone, the bars were all of equal width. Tuning was done by cutting the bars to different lengths and removing material from the bottom. Using a router I created a sort of 'stepped pyramid' instead of the traditional arc cut found on marimba or xylophone bars. Cutting the underside is not only for tuning but it focuses the pitch and creates the characteristic overtones of the instrument. Since I wanted to play this with other 'Western' instruments, I chose to use a pentatonic scale of 2 2/5 octaves (C#,D#,F#,G#,A#,C#,D#,F#,G#,A#,C#,D#). Two people sit on either side of the instrument and strike the ends of ...
